A compact, all-in-one simultaneous multi-operational service cart designed for full SF₆ gas handling on medium and high voltage equipment, combining recovery, air evacuation, refilling, and filtration in a single robust unit.

CAR108-01

Request info

Watch the video

Features and Benefits

All-in-one compact cart (all functions in a single robust unit)

Simultaneous multi-operational system

Compliant gas recovery (< 1 mbar absolute, in acc. with CEI EN 62271-4)

Autonomous gas recycling (integrated filtration for moisture and by-products)

Certified weighing monitoring (for safe and efficient gas management)

Zero-leakage molecular safety

Technical Specifications

Robust gas maintenance unit equipped with an oil-free SF₆ compressor, dry suction and air vacuum pumps, integrated filtration, 180 kg load cell weighing system, and multiple independent digital/analog monitoring readouts.

Dimensions

Length: 680 mm (wheels)
Length: 550 mm (chassis)
Width: 930 mm
Height: 1350 mm

Weight

240 kg

Voltage

230V 50/60Hz single-phase
110V 50/60Hz single-phase

SF₆ oil-free compressor
Nominal flow rate

2,4 Nm³/h (50 Hz)
2,7 Nm³/h (60 Hz)

SF₆ dry suction pump
Nominal flow rate

3 m³/h (50 Hz)
3,6 m³/h (60 Hz)

Air vacuum pump
Nominal flow rate

15 m³/h (50 Hz)
18 m³/h (60 Hz)
