SF6 gas analyser
Available in two versions to meet any kind of SF6 gas analysis need:
COD. ALY101-05 SF6 gas analyser
COD. ALY101-06 SF6 gas analyser full
Features and benefits
Features and benefits
-
01
Different measurable parameters to verify the purity of the gas according to the CEI EN 60480: SF6 SO2 CO H2S HF and dew-point
-
02
Accurate and quick analysis
-
03
Downloadable data on USB stick
-
04
The absence of SF6 gas leaks is guaranteed by a closed-loop system
-
05
Special flexible bag for gas storage
-
06
Internal rechargeable battery for different analyses with a single charge
-
07
Analyzed gas stored inside the analyzer can be returned to the compartment through the pump-back function or the device can be used as an analysis tool for a continuous flow
-
Dimensions
Length: 428 mm
Width: 555 mm – Height 306 mm -
Weight
24 kg
-
SF6 sensor (infrared)
Detection Limit < 0,1Vol.%
-
Dew-point sensor
Measuring range: -80°C … +20°Ctd
-
SO2 sensor (electrochemical)
Nominal range: 0-100 ppm (also available 0-20 or 0-500)
-
CO sensor (electrochemical)
Nominal Range: 0-1000 ppm
-
H2S sensor (electrochemical)
Nominal Range: 0-100 ppm
-
HF sensor (electrochemical)
Nominal Range: 0-10 ppm
Download
Download technical sheet
Request info
+39 035 4376691
