Sniffer SF6
SF6 Sniffer by Synecom is a portable instrument capable of performing SF6 leak detection. The instrument has a full scale of 1×10-6 mbar l/s.
The detector can automatically adapt the measurement range in relation to the various concentrations of gas present in the detection site.
COD. LEK102-01
Features and benefits
Features and benefits
-
01
Full scale of 1×10-6 mbar l/s
-
02
Audible and visual alarms
-
03
Automatic adjustment of measuring range
Technical Specifications
The instrument is equipped with audible and visual alarms via an easy-to-understand LED graphic display.
-
Instrument sensitivity
1×10-6 mbar l/s
-
Response time
ABOUT 1 SECOND
-
Audio
AUDIBLE SIGNALING OF GAS LEAKAGE SF6
-
Display
LED BAR 7 POSITIONS
-
Probe
355MM FLEXIBLE TUBE
-
Operating temperature range
FROM -20 °C TO + 50 °C
-
EMC rating
CE DECLARATION OF CONFORMITY
-
Case
L 330 mm, W 280 mm, H 125 mm
-
Weight
2.1 kg
Download
Download technical sheet
